CLI方式：手动离线升级病毒特征库典型配置

使用版本

本举例是在F5000-AI160的E8371版本上进行配置和验证的。

组网需求

如下图所示，位于Trust安全域的局域网用户通过Device可以访问Untrust安全域的Internet资源，以及DMZ安全域的FTP服务器。FTP服务器根目录下保存了最新的病毒特征库文件anti-virus-1.0.8-encrypt.dat，FTP服务器的登录用户名和密码分别为anti-virus和123。现需要手动离线升级病毒特征库，加载最新的病毒特征。

图-3 手动离线升级病毒特征库配置组网图

‌

配置步骤

  1. 配置接口IP地址

# 根据组网图中规划的信息，配置各接口的IP地址，具体配置步骤如下。

<Device> system-view

[Device] interface gigabitethernet 1/0/1

[Device-GigabitEthernet1/0/1] ip address 192.168.1.1 255.255.255.0

[Device-GigabitEthernet1/0/1] quit

请参考以上步骤配置其他接口的IP地址，具体配置步骤略。

  1. 配置静态路由

本举例仅以静态路由方式配置路由信息。实际组网中，请根据具体情况选择相应的路由配置方式。

# 请根据组网图中规划的信息，配置静态路由，本举例假设到达外网Web Server的下一跳IP地址为2.2.2.2，实际使用中请以具体组网情况为准，具体配置步骤如下。

[Device] ip route-static 5.5.5.0 24 2.2.2.2

  1. 配置接口加入安全域

# 请根据组网图中规划的信息，将接口加入对应的安全域，具体配置步骤如下。

[Device] security-zone name trust

[Device-security-zone-Trust] import interface gigabitethernet 1/0/1

[Device-security-zone-Trust] quit

[Device] security-zone name untrust

[Device-security-zone-Untrust] import interface gigabitethernet 1/0/2

[Device-security-zone-Untrust] quit

[Device] security-zone name dmz

[Device-security-zone-DMZ] import interface gigabitethernet 1/0/3

[Device-security-zone-DMZ] quit

  1. 配置安全策略

[Device] security-policy ip

[Device-security-policy-ip] rule name trust-untrust

[Device-security-policy-ip-10-trust-untrust] source-zone trust

[Device-security-policy-ip-10-trust-untrust] source-ip-subnet 192.168.1.0 24

[Device-security-policy-ip-10-trust-untrust] destination-zone untrust

[Device-security-policy-ip-10-trust-untrust] action pass

[Device-security-policy-ip-10-trust-untrust] quit

[Device] security-policy ip

[Device-security-policy-ip] rule name trust-dmz

[Device-security-policy-ip-11-trust-dmz] source-zone trust

[Device-security-policy-ip-11-trust-dmz] source-ip-subnet 192.168.1.0 24

[Device-security-policy-ip-11-trust-dmz] destination-zone dmz

[Device-security-policy-ip-11-trust-dmz] action pass

[Device-security-policy-ip-11-trust-dmz] quit

[Device] security-policy ip

[Device-security-policy-ip] rule name downloadlocalout

[Device-security-policy-ip-12-downloadlocalout] source-zone local

[Device-security-policy-ip-12-downloadlocalout] destination-zone dmz

[Device-security-policy-ip-12-downloadlocalout] destination-ip-subnet 192.168.2.0 24

[Device-security-policy-ip-12-downloadlocalout] application ftp

[Device-security-policy-ip-12-downloadlocalout] application ftp-data

[Device-security-policy-ip-12-downloadlocalout] action pass

[Device-security-policy-ip-12-downloadlocalout] quit

# 激活安全策略配置。

[Device-security-policy-ip] accelerate enhanced enable

[Device-security-policy-ip] quit

  1. 手动升级防病毒特征库

# 采用FTP方式手动离线升级设备上的病毒特征库，被加载的病毒特征库文件名为anti-virus-1.0.8-encrypt.dat。

[Device] anti-virus signature update ftp:// anti-virus:123@192.168.2.4/anti-virus-1.0.8-encrypt.dat

验证配置

病毒特征库升级后，可以通过display anti-virus signature library命令查看当前特征库的版本信息。

配置文件

Device

#

interface GigabitEthernet1/0/1

 ip address 192.168.1.1 255.255.255.0

#

interface GigabitEthernet1/0/2

 ip address 2.2.2.1 255.255.255.0

#

interface GigabitEthernet1/0/3

 ip address 192.168.2.1 255.255.255.0

#

security-zone name Trust

 import interface GigabitEthernet1/0/1

#

security-zone name DMZ

 import interface GigabitEthernet1/0/3

#

security-zone name Untrust

 import interface GigabitEthernet1/0/2

#

 ip route-static 5.5.5.0 24 2.2.2.2

#

security-policy ip

 accelerate enhanced enable

 rule 0 name trust-untrust

  action pass

  source-zone trust

  destination-zone untrust

  source-ip-subnet 192.168.1.0 255.255.255.0

 rule 1 name trust-dmz

  action pass

  source-zone trust

  destination-zone dmz

  source-ip-subnet 192.168.1.0 255.255.255.0

 rule 2 name downloadlocalout

  action pass

  source-zone local

  destination-zone dmz

  destination-ip-subnet 192.168.2.0 255.255.255.0

  application ftp

  application ftp-data

#

anti-virus signature update ftp://anti-virus:123@192.168.2.4/anti-virus-1.0.8-encrypt.dat

#
